The BV073 is a two-panel double V-Gate for wide pedestrian openings in safety barrier runs. Spanning 2000mm overall (2377mm including posts), the two panels meet in the centre and each closes independently.
Suited to wider barrier openings where a single 1000mm gate cannot span the gap. Both panels are self-closing. 1000mm high. Complete with posts, gate furniture and all fixings.
For a narrower double gate (1520mm), choose the BV074. For single gates up to 1000mm, choose the BV071 (left hand) or BV072 (right hand).
Need a bulk quote? Contact us here.
| Component | Code | Quantity |
|---|---|---|
| Double gate panel assembly (x2) | 2 | |
| Gate posts | Included | |
| Gate furniture, hinges, and closers | Included | |
| All fixings | Included |
Pedestrian gates create a controlled access point within a safety barrier run. They let pedestrians pass through a barrier line without breaking it, and self-closing hinges mean the opening seals shut again the moment someone walks through, rather than being left propped open.
V-Gates are the standard choice for pedestrian-only openings in warehouses, factories, and distribution centres, placed where a walkway passes through a barrier protecting a work area, machine perimeter, or mezzanine edge. Swing Boom Gates handle the same opening but with a horizontal boom that swings out of the way for forklift or vehicle access, then closes back across the pedestrian path to maintain separation when vehicles aren’t passing. Vivid Gates add a warning light and audible alarm that activate when the gate is open, flagging an open barrier point in high-traffic environments. Double V-Gates cover wider openings that a single gate can’t span.
Common applications include warehouse pedestrian crossings, mezzanine stair and lift landings, machine access points, loading area pedestrian paths, and anywhere a safety barrier run needs a gated opening that stays closed.
V-Gates and Swing Boom Gates suit most standard pedestrian openings in barrier runs. Choose a single V-Gate for a pedestrian-only opening up to 1000mm wide, a 750mm model for tighter gaps, a Double V-Gate or Swing Boom Gate for wider spans, and the Vivid Gate where you need an open-gate alarm in addition to the self-closing function. Pair gates with HD barriers or ECO-Rail handrail to complete the barrier run on both sides.
